Description
Features
• 6.2″ 800×480 Touch-Screen Display
• Mechless Unit (No CD/DVD Player)
• Built-in Bluetooth with Audio Streaming
• External Microphone Included (3.5mm)
• Front 1.5A USB Input (iPod / iPhone Compatible)
• Front AUX Input (3.5mm)
• Rotary Volume Control
• WebLink Screen Mirroring (for supported phones)
• Quick wake-up
• Extra Bass
• Dynamic Stage Organizer
• 10-band Graphic Equalizer
• White Key Illumination
• MP3/WMA/AAC/FLAC/MPEG4/H.264/WMV/MKV/XviD Playback
• RDS
• Rear Reverse Camera Input (with adjustable gridlines)
• RCA Audio Output (2 Pair)
• Subwoofer RCA Output
• ISO Loom Adapter Included
• Mounting Cage & Trim Included
• Rear Wired Remote Input (3.5mm)
– with Learning Function required 3mm jack.
Specifications
• Power Requirement: 12V DC Negative Ground (11V-16V acceptable)
• FM Tuning Range: 87.5 – 108.0 MHz (NZ frequency)
• AM Tuning Range: 531 – 1,602 kHz (NZ frequency)
• Speaker Output: 55W x 4 (4Ω)
• Speaker Impedance: 4Ω (4-8Ω acceptable)
Size
• Width: 178mm
• Height: 100mm
